Three batteries, two jumpers and a charger lead on every post — 36V rigging is where mistakes happen. The RCE36VBCHK replaces all of it with plug-and-play connectors that series-wire three 12V batteries correctly every time and keep each bank of your on-board charger connected.
Connect-Ease's patented, self-cleaning, positive-lock connectors replace wing nuts and stacked ring terminals at the battery. Install once and every connection after that is plug-and-play — the system wires your batteries correctly every time, and integrated charging leads keep your on-board charger connected while you fish, trailer or store the boat.
Compatible trolling motors and vehicles: Minn Kota Ultrex, Ulterra, Terrova and Riptide (36V / 101–112 lb, incl. QUEST models); Garmin Force (36V); Lowrance Ghost (36V); MotorGuide Tour Pro and Xi5 (36V).
System voltage: 36V (three 12V in series). Recommended batteries: Three 12V AGM/flooded/LiFePO4 batteries in series, or one 36V single-case lithium (60–120Ah). Amperage and protection: 36V motors (101–112 lb) draw up to ~52A at full throttle. Protect with a 60A resettable breaker.
A plug-and-play 36V series battery connection system with integrated on-board charging leads — designed for serious anglers who need fast, foolproof battery removal and replacement without tools, even in tight compartments. Correctly connects three 12V batteries in series every time.
• Series-wires three 12V batteries for 36V — no crossed jumpers
• Integrated charging leads for 3-bank on-board chargers
• Self-cleaning, positive-lock connectors
• Remove any battery in seconds without tools
• AGM and lithium compatible
-
Wire: 8-gauge UL1426 tinned marine-grade wire with heat-shrink butt splices
-
Charging: Integrated multi-bank on-board charging leads — pre-wired for multi-bank charger connection
-
Connectors: Self-cleaning, positive-lock plug-and-play connections — no tools required after installation
-
Compatibility: All 36V trolling motor brands and models; AGM and lithium battery compatible
-
Rating: Saltwater approved; 1-year warranty; Made in the USA
-
Patent No.: 9,559,473 / 9,866,047
Compatible Trolling Motors:
- Minn Kota Ultrex
- Ulterra
- Terrova
- Riptide (36V / 101–112 lb, incl. QUEST models)
- Garmin Force (36V)
- Lowrance Ghost (36V)
- MotorGuide Tour Pro and Xi5 (36V)
Recommended Voltage/ Amperage/ Fuse/ Breaker:
36V (three 12V in series), 36V motors (101–112 lb) draw up to ~52A at full throttle. Protect with a 60A resettable breaker
Battery Types:
Three 12V AGM/flooded/LiFePO4 batteries in series, or one 36V single-case lithium (60–120Ah)
FAQ: Will this work with a 3-bank on-board charger?
A: Yes. Integrated leads connect each 12V battery to its own charger bank.
FAQ: I have one 36V lithium — is this right?
A: No. For a single 36V lithium battery, choose the Ignite 36V (RCE36VSCK).
