For lighter 12V loads — fish finders, livewell pumps, LED lights and accessories — the RCE12VB10 provides a 10-gauge plug-and-play connection to your battery. It keeps accessories off your main battery posts and lets you disconnect for charging in seconds.
Stacking ring terminals on a battery post invites corrosion, loose connections and blown fuses at the worst time. A Connect-Ease hub gives every accessory its own plug-and-play lead off one clean battery connection, so you can add, remove or troubleshoot devices without touching the battery.
Compatible electronics and accessories: Fish finders, GPS, VHF radios, bilge pumps, livewell pumps, LED lighting, USB chargers and shallow-water anchors; single graphs such as Humminbird HELIX, Garmin STRIKER or Lowrance Elite.
System voltage: 12V. Recommended batteries: 12V deep-cycle AGM, flooded lead-acid or 12.8V LiFePO4 lithium (Group 24/27/31, 50–120Ah). Amperage and protection: Fuse each accessory to its maker's rating (typically 3–15A).
This quick connect system is designed to quickly and easily hook up a 12 Volt trolling motor, battery charger, light, radio, depth finder or other equipment quickly, by just snapping the connectors together.
Self-cleaning marine-grade connectors last for years. This device has endless uses for the outdoors, can be used for Boats, ATVs, RVs, Ice Houses, Agricultural Equipment, Solar Panels or anywhere you want to share a quick and easy connection with one or multiple batteries, the uses are endless.
Once your Connect-Eaze is installed, no tools are needed for the removal, replacement or storage of expensive marine batteries. Using the Connect-Ease series of products allows connecting any 12V marine battery with any equipment or device at any time, any place, easily and quickly. Just snap the connectors together and you're done!
• 10-gauge marine-grade lead for accessories
• Self-cleaning, positive-lock connector
• Keeps battery posts clean and uncluttered
• Mates with all red Connect-Ease systems
• Lithium compatible
FEATURES:
- 10-gauge marine-grade wire with heat-shrinkable butt splice.
- Single-use lead for chargers, lights, small trolling motors, and more.
- Plug & Play Connections Lithium Compatible.
- Suitable for use t-40° to 221°
Lithium Compatible
- UL1426 Tinned Marine Grade Wire - One-year Warranty – Salt Water Approved
- 10 AWG 5 “ Device Connections
- 50 AMP Rating
- Made In the USA (Patent Pending )
Recommended Voltage/ Amperage/ Fuse/ Breaker:
12V Fuse each accessory to its maker's rating (typically 3–15A)
Battery Types:
12V deep-cycle AGM, flooded lead-acid or 12.8V LiFePO4 lithium (Group 24/27/31, 50–120Ah)
FAQ: Can I run a trolling motor on 10-gauge?
A: No. Use 8- or 6-gauge for trolling motors. The 10-gauge connector is for accessories and electronics.
FAQ: Does it include a fuse?
A: Add an in-line fuse sized to your device; Connect-Ease fused kits are also available.
