.When the load is serious, the RCE12VB6 delivers. This 6-gauge, heavy-duty Connect-Ease lead handles outboard starting circuits, winches, power-poles and high-amp accessories with a secure, self-cleaning plug-and-play connection.
Connect-Ease's patented, self-cleaning, positive-lock connectors replace wing nuts and stacked ring terminals at the battery. Install once and every connection after that is plug-and-play — no tools, no crossed wires, no corroded posts, and batteries come out in seconds for charging or winter storage.
Compatible trolling motors and vehicles: Minn Kota Endura, Traxxis, PowerDrive, Terrova and Riptide (12V models); MotorGuide X3, R3 and Xi3 (12V); Newport Vessels and Watersnake 12V motors.
System voltage: 12V. Recommended batteries: 12V marine starting / dual-purpose battery (AGM, flooded or lithium with starting BMS), Group 24–31. Amperage and protection: High-current 6-gauge lead — protect with a fuse/breaker matched to the device.
A heavy-duty 6-gauge single connection with butt splice for outboard motors and demanding land and water applications. Creates a foolproof, corrosion-free quick-connect for any single-battery setup — no cutting, splicing, or soldering required.
• 6-gauge wire for outboards and high-amp loads
• Self-cleaning, positive-lock connector
• Waterproof heat-shrink terminations
• Mates with all red Connect-Ease systems
• Lithium and AGM compatible
-
Wire: 6-gauge UL1426 tinned marine-grade wire with butt splice
-
Connectors: Self-cleaning, positive-lock plug-and-play connections — no tools required after installation
-
Applications: Outboard motors, kicker motors, trolling motors, winches, snow plows, generators, and more
-
Current Rating: UL1977 rated — 120A capacity
-
Temperature Range: −40°F to 221°F
-
Compatibility: AGM and lithium battery compatible
Compatible Trolling Motors:
- Minn Kota Endura
- Traxxis
- PowerDrive
- Terrova
- Riptide (12V models)
- MotorGuide X3, R3 and Xi3 (12V)
-
Newport Vessels and Watersnake 12V motors
Recommended Voltage/ Amperage/ Fuse/ Breaker:
12V High-current 6-gauge lead — protect with a fuse/breaker matched to the device
Battery Types:
12V marine starting/ dual-purpose battery (AGM, flooded or lithium with starting BMS), Group 24–31
FAQ: Can this handle my outboard's starter?
A: It's designed for outboard and heavy-duty applications. Confirm your engine maker's cable gauge recommendation for long runs.
FAQ: Is it compatible with my existing kit?
A: Yes, it mates with all red Connect-Ease connectors.
