Modern electronics — especially forward-facing sonar and multiple graphs — demand clean, dedicated power. Graph Power is a complete plug-and-play wiring system that routes high-quality power from the battery to console and bow without sharing circuits or creating interference. Choose the size that fits your rig: 10 ft for tillers and small boats, 16–18 ft for mid-size console boats, or 19–22 ft for full-size bass and multi-species boats.
Today's forward-facing sonar and multi-graph setups are sensitive to voltage drop and electrical noise. Connect-Ease clean-power wiring gives each device its own fused, dedicated circuit back to a clean 12V house battery — no shared trolling motor circuits and no piggy-backed ring terminals — so screens stay crisp, sonar stays quiet and units don't reboot under load.
Compatible electronics and accessories: Humminbird HELIX, SOLIX, APEX and MEGA Live 2; Garmin ECHOMAP UHD2, GPSMAP and LiveScope Plus / XR (GLS 10 black box); Lowrance HDS PRO, HDS Live, Elite FS and ActiveTarget 2; Raymarine Axiom and Element.
System voltage: 12V house battery (lithium compatible). Recommended batteries: Dedicated 12V house battery: 12.8V LiFePO4 (20–50Ah) recommended for forward-facing sonar; AGM also works. Up to 16V lithium supported where noted. Amperage and protection: 30A fuse at the battery; 3A or 5A fuse at each graph, transducer box or FFS black box as your electronics maker specifies.
Eliminate interference and voltage drop. Graph Power kits deliver dedicated clean power to console and bow electronics. Perfect for Garmin, Lowrance, Humminbird & forward-facing sonar.
Modern electronics (especially forward-facing sonar and multiple graphs) demand clean, dedicated power. The Graph Power Pro is a complete plug-and-play wiring system that routes high-quality power from the battery to both console and bow without sharing circuits or creating interference.
-
Key Features:
– Console backbone + Bow backbone with multiple fused drops
– 8-gauge marine-grade sheathed wire
– Easy-feed design for clean routing
– Lithium compatible
– No cutting, splicing, or soldering required after initial install
– Designed for 10–22 ft fishing boats, pontoons, kayaks
-
Benefits for the angler:
– Sharper sonar images
– Stable voltage under load
– Reduced electrical noise
– Faster, cleaner installation than traditional methods
-
Compatible Electronics: Garmin, Lowrance, Humminbird, Ray marine, etc.
- Installation Instruction on packages
Not just another wiring kit—it’s a purpose-built system engineered to eliminate the most common problems anglers face: power interference, voltage drops, and unreliable connections.
With dedicated clean power delivery, your graphs and sonar units perform at their absolute best:
- Crystal-clear imaging with no screen flicker
- Consistent voltage for peak sonar performance
- Zero interference from other onboard electronics
Whether you're running Garmin®, Humminbird®, or Lowrance®, Graph Power Pro ensures your electronics deliver the full picture—every time. Available in multiple lengths to accommodate everything from Kayaks to large fishing boats.
• Three sizes: 10 ft, 16–18 ft and 19–22 ft
• Console and bow backbones with multiple fused drops (16–18 and 19–22 ft)
• 8-gauge marine-grade sheathed wire
• Easy-feed design for clean routing
• No cutting, splicing or soldering after install
• Lithium compatible
Compatible Fish Finder:
- Humminbird HELIX
- SOLIX
- APEX and MEGA Live 2
- Garmin ECHOMAP UHD2
- GPSMAP and LiveScope Plus / XR (GLS 10 black box)
- Lowrance HDS PRO
- HDS Live
- Elite FS and ActiveTarget 2
- Raymarine Axiom and Element
Recommended Voltage/ Amperage/ Fuse/ Breaker:
12V house battery (lithium compatible), 30A fuse at the battery; 3A or 5A fuse at each graph, transducer box or FFS black box as your electronics maker specifies
Battery Types:
Dedicated 12V house battery: 12.8V LiFePO4 (20–50Ah) recommended for forward-facing sonar; AGM also works. Up to 16V lithium supported where noted
FAQ: Which size do I need?
A: 10 ft for tillers, kayaks and small boats; 16–18 ft for mid-size console boats; 19–22 ft for full-size bass and multi-species boats.
FAQ: What problems does it solve?
A: Screen flicker, sonar noise, unit reboots and voltage drop caused by shared or undersized wiring.
graph power wiring kit, fish finder wiring by boat size; tiller boat electronics wiring; console boat electronics harness; clean power for sonar
